SPECIFICATION

1,Working Medium:Air source

2,Body material:Aluminum die-casting

3,Filter bowl and Lubricator bowl material:PC

4,Filter element material:Brass

5,Bowl Guard:Aluminum alloy

6,Seal Material:NBR

7,Adjustabing knob:POM

8,Working pressure:1~8.5Bar standard,high pressure 0~15Bar available for requirement

9,Working Temperature:-5~60℃

10,Filtration fineness:40µ,5µ can be available

11,Mounting type: Pipe mounting or bracket support mounting

12,Regulator type:Diaphragm type

13,Lubricator type:Oil volume adjustable during working

14,Port size:PT1/4”,PT3/8”,PT1/2”

15,Drainage model:Manual drainer,Semi-automatic drainer,automatic drainer

16,Oil cup capacity:200cc

17,Design type:Modular
